IAC Idle Air Control Valve 17059603 Fits Buick Chevrolet Optra/Lacetti 2007-2012 93744875/9374 4875 / C2177 / 93744675

SHOPPING GUIDE

If there is any CUSTOM DUTIES,ATION FEES,buyer will bear these costs. Each country has different customs threshold, so you need know your country's policy. Please must make sure your car type same one type of our product link. Please must check our product photos in the link if same your old part.we hope you can get correct goods. Please kindly find your part of number depend our photo.then confirm same number on our web or contact us. The number will appear anywhere in the part.

Type Name:

Stepper Motor / IACV / Idle air Control Valve

Interchange Part Number:

817253, 817255, 17112023, 17112031

Other Part Number:

A95214, 17059603, 59603, 817253, 817255, 17112023, 17112031

TECHNICAL PARAMETER:

Oeperateing Temperature Range:-40℃-125℃(150℃ peak)

Nominal Operating Voltage:12VDC

MIN/MAX Operating Voltage:7.5V-14VDC

Resistance Per Winding (@25℃):53Ω±10%

Minimum Resistance (@-40℃):35Ω

Solenoid inductance:33mH±20%

Step Increment :0.04167mm

MAX travel:8.5mm(204step)

Application :

ChangHe Polaris

HaFei 1.0-1.2L Song Hua jiang

Soueast-motor 2.2L

opel

ASCONA C (81_, 86_, 87_, 88_) 1.6 i E16NZ 1598CC 55KW 1987-1988

ASCONA C (81_, 86_, 87_, 88_) 1.6 i CAT C16NZ 1598CC 55KW 1986-1988

ASCONA C Hatchback (84_, 89_) 1.6 i E16NZ 1598CC 55KW 1987-1988

ASCONA C Hatchback (84_, 89_) 1.6 i CAT C16NZ 1598CC 55KW 1986-1988

ASTRA F (56_, 57_) 1.6 i C16NZ 1598CC 55KW 1992-1998

ASTRA F (56_, 57_) 1.6 i X16SZ 1598CC 52KW 1993-1996

ASTRA F (56_, 57_) 1.6 i X16SZR 1598CC 55KW 1996-1998

ASTRA F (56_, 57_) 1.8 i C18NZ 1796CC 66KW 1992-1998

ASTRA F Convertible (53_B) 1.6 i X16SZ 1598CC 52 KW 1993-1996

ASTRA F Convertible (53_B) 1.6 i X16SZR 1598CC 55 KW 1996-2001

ASTRA F Estate (51_, 52_) 1.6 16LZ2 1598CC 55KW 1995-1998

ASTRA F Estate (51_, 52_) 1.6 i C16NZ 1598CC 55KW 1991-1998

ASTRA F Estate (51_, 52_) 1.6 i X16SZ 1598CC 52KW 1993-1996

ASTRA F Estate (51_, 52_) 1.8 i C18NZ 1796CC 66KW 1991-1998

ASTRA F Hatchback (53_, 54_, 58_, 59_) 1.6 16LZ2 1598CC 55KW 1995-1998

ASTRA F Hatchback (53_, 54_, 58_, 59_) 1.6 i C16NZ 1598CC 55KW 1991-1998

ASTRA F Hatchback (53_, 54_, 58_, 59_) 1.6 i X16SZ 1598CC 52KW 1993-1996

ASTRA F Hatchback (53_, 54_, 58_, 59_) 1.8 i C18NZ 1796CC 66KW 1991-1998

ASTRA F Van (55_) 1.6 i C16NZ 1598CC 55KW 1991-1993

ASTRA F Van (55_) 1.6 i X16SZ 1598CC 52KW 1993-1996

ASTRA G Box (F70) 1.6 X 16SZR 1598CC 55KW 1999-2000

ASTRA G Estate (F35_) 1.6 X16SZR 1598CC 55KW 1998-2000

ASTRA G Hatchback (F48_, F08_) 1.6 X16SZR 1598CC 55KW 1998-2000

ASTRA G Saloon (F69_) 1.6 X16SZR 1598CC 55KW 1998-2000

COMBO (71_) 1.4 C14NZ 1389CC 44KW 1994-2001

CORSA A Hatchback (93_, 94_, 98_, 99_) 1.6 GSI C16NZ 1598CC 55KW 1988-1992

CORSA B (73_, 78_, 79_) 1.4 i C14NZ 1389CC 44KW 1993-2000

CORSA B Box (73_) 1.4 i X14SZ 1389CC 44KW 1999-2000

KADETT E (39_, 49_) 1.6 i E16NZ 1598CC 55KW 1986-1991

KADETT E (39_, 49_) 1.6 i CAT C16LZ 1598CC 55KW 1986-1991

KADETT E (39_, 49_) 1.8 i C18NT 1796CC 66KW 1990-1991

KADETT E Box (37_, 47_) 1.6 i C16NZ 1598CC 55KW 1989-1993

KADETT E Combo (38_, 48_) 1.6 i C16NZ 1598CC 55KW 1991-1994

KADETT E Convertible (43B_) 1.6 i E16NZ 1598CC 55KW 1986-1993

KADETT E Convertible (43B_) 1.6 i CAT C16LZ 1598CC 55KW 1987-1993

KADETT E Estate (35_, 36_, 45_, 46_) 1.6 i E16NZ 1598CC 55KW 1986-1991

KADETT E Estate (35_, 36_, 45_, 46_) 1.6 i CAT C16LZ 1598CC 55KW 1986-1991

KADETT E Estate (35_, 36_, 45_, 46_) 1.8 i C18NT 1796CC 66KW 1985-1991

KADETT E Hatchback (33_, 34_, 43_, 44_) 1.6 i E16NZ 1598CC 55KW 1986-1991

KADETT E Hatchback (33_, 34_, 43_, 44_) 1.6 i CAT C16LZ 1598CC 55KW 1986-1991

KADETT E Hatchback (33_, 34_, 43_, 44_) 1.8 i C18NT 1796CC 66KW 1985-1991

VECTRA A (86_, 87_) 1.6 i E16NZ 1598CC 55KW 1988-1995

VECTRA A (86_, 87_) 1.6 i X16SZ 1598CC 52KW 1993-1995

VECTRA A (86_, 87_) 1.6 i CAT C16NZ 1598CC 55KW 1988-1995

VECTRA A (86_, 87_) 1.8 i CAT C18NZ 1796CC 66KW 1990-1995

VECTRA A Hatchback (88_, 89_) 1.6 i X16SZ 1598CC 52KW 1993-1995

VECTRA A Hatchback (88_, 89_) 1.6 i CAT C16NZ 1598CC 55KW 1988-1995

VECTRA A Hatchback (88_, 89_) 1.8 i CAT C18NZ 1796CC 66KW 1990-1995

VECTRA B (36_) 1.6 i X16SZR 1598CC 55KW 1995-2002

VECTRA B (36_) 1.6 i 16LZ2 1598CC 55KW 1995-2002

VECTRA B Estate (31_) 1.6 i X16SZR 1598CC 55KW 1996-2000

VECTRA B Estate (31_) 1.6 i 16LZ2 1598CC 55KW 1996-2000

VECTRA B Hatchback (38_) 1.6 i X16SZR 1598CC 55KW 1995-2003

VECTRA B Hatchback (38_) 1.6 i 16LZ2 1598CC 55KW 1995-2003

VAUXHALL

ASTRA Mk III (F) 1.6 i C16NZ 1598CC 55KW 1992-1998

ASTRA Mk III (F) 1.6 i X16SZ 1598CC 52KW 1994-1996

ASTRA Mk III (F) 1.8 i C18NZ 1796CC 66KW 1992-1998

ASTRA Mk III (F) Convertible 1.6 i X16SZ 1598CC 52KW 1993-1996

ASTRA Mk III (F) Convertible 1.6 i X16SZR 1598CC 55KW 1996-2001

ASTRA Mk III (F) Estate 1.6 i C16NZ 1598CC 55KW 1991-1998

ASTRA Mk III (F) Estate 1.6 i X16SZ 1598CC 52KW 1994-1998

ASTRA Mk III (F) Estate 1.8 i C18NZ 1796CC 66KW 1991-1998

ASTRA Mk III (F) Hatchback 1.6 i C16NZ 1598CC 55KW 1991-1998

ASTRA Mk III (F) Hatchback 1.6 i X16SZ 1598CC 52KW 1994-1998

ASTRA Mk III (F) Hatchback 1.8 i C18NZ 1796CC 66KW 1991-1998

ASTRA Mk IV (G) 1.6 X16SZR 1598CC 55KW 1998-2000

ASTRA Mk IV (G) Estate 1.6 X16SZR 1598CC 55KW 1998-2004

ASTRA Mk IV (G) Hatchback 1.6 X16SZR 1598CC 55KW 1998-2000

ASTRAVAN Mk III (F) 1.6 i C16NZ 1598CC 55KW 1991-1998

ASTRAVAN Mk III (F) 1.6 i X16SZ 1598CC 52KW 1994-1996

ASTRAVAN Mk IV (G) 1.6 i X16SZR 1598CC 55KW 1998-2000

CAVER Mk II 1.6 i E16NZ 1598CC 55KW 1986-1988

CAVER Mk III (87) 1.6 i E16NZ 1598CC 55KW 1988-1995

CAVER Mk III (87) 1.6 i X16SZ 1598CC 52KW 1993-1995

CAVER Mk III (87) 1.8 i CAT C18NZ 1796CC 66KW 1990-1995

CORSA Mk II (B) 1.4 i C14NZ 1389CC 44KW 1993-2000

VECTRA (B) 1.6 i X16SZR 1598CC 55KW 1995-2001

VECTRA (B) Estate 1.6 i X16SZR 1598CC 55KW 1996-2002

VECTRA (B) Hatchback 1.6 i X16SZR 1598CC 55KW 1995-2001

Warranty:

1 Year Unlimited Mileage Guarantee.

Package : 1xIdle Air Control Valve

About shipping
Shipping and Packaging All it will be double checked and well packed before sending.It will be dispatched within 2 business days ar buyers pay for the order. It usually takes about 14 to 18 working days for delivering the package to the destination(for remote areas,it may take a little longer).

Special Announcement:
Please fill in the correct and detailed consignee, address and phone number in the order. For fast and correct delivery.If you do not receive order within 30 working days,please feel free to contact Customer Service before leaving Negative and Neutral Feedback, we will do our best to help you resolve the problem.TaxNo, you will only pay what is quoted as total cost at checkout, no more. You are not expected to pay any additional duties ores. If you are asked by Customs or our logistic partner to pay duties, please contact our Customer Service .

Your 100% satisfaction is very ant to us
If the product is not on good condition, You can return this product within 14 working days, please contact customer service center before returning.FeedbackYour satisfaction is our first priorityIf you receive the order and it is in good condition,we would be grateful if you would leave us 5 star Positive Feedback for the transaction.

Key Features

Model Number:LRD-59603
Material:Magnet / PA66-GF30 / Copper
Product Name:Idle Air Control Valve
Warranty:3 Years
Quty:OEM Quty
OE/ Part Number 1:A95214
OE/ Part Number 2:17059603
OE/ Part Number 3:817253
OE/ Part Number 4:817255
OE/ Part Number 5:17112023, 17112031
OE/ Part Number 6:A95 214, 170 596 03, 596 03, 817 253, 817 255, 171 120 23, 171 120 31
Condition:100%
Car Model 1:For GM Buick Chevrolet
Car Model 2:For Buick Chevrolet Optra/Lacetti 2007-2012

What's In the Box

1X LOREADA IAC Idle Air Control Valve 17059603 Fits Buick Chevrolet Optra/Lacetti 2007-2012 93744875/9374 4875 / C2177 / 93744675
