P-7000S Power Amplifier

The P-Series Power Amplifiers deliver a robust amount of professional quality power in a wide range of configurations.A powerful amplifier with power switch (push ON/OFF), light indicator, Two 31-step volume control knob (One per channel), Mode switch (STEREO/PARALLEL/BRIDGE), Two Fc knobs (25 to 150HZ, 12 bB/octave), Ys processing switch (ON/OFF), XLR 3-31 Jacks (One per channel), Speakon Jacks(One per channel), 5-way binding posts, 1/4 inch TRS phone jacks (One per channel) and many more features. Those on a budget will find the lineup's high power output and affordable prices deliver higher quality without putting a strain on funds. Further savings are realized with extremely efficient operation utilizing exclusive Engine technology which keeps operational costs down by significantly reducing AC power consumption and heat generation.can efficiently be used in Churches, schools, mosques and event centers.speakersfront-panel LEDs indicate Power, Active Status, and Protection Warning for easier troubleshooting.

Key Features

Maximum Input Voltage: 32.1dB
Power Requirements: AC120V 60Hz
Power Consumption: 650W
2-channel Pro Audio amplifierpower output at 20-20,000 Hz:
750 watts RMS per channel at 8 ohms950 watts RMS per channel at 4 ohms1900 watts RMS (mono) at 8 ohms in bridged modepower output at 1 kHz:
750 watts RMS per channel at 8 ohms1100 watts RMS per channel at 4 ohms2200 watts RMS (mono) at 8 ohms in bridged mode3200 watts RMS (mono) at 4 ohms in bridged modefrequency response: 20-50,000 Hz (-1.5 dB)signal-to-noise ratio:
104 dBinputs: XLR and 1/4" TRS for channels A and Boutputs
Neutrik Speakon jacks, 5-way binding posts, 1/4" jacksindependent right- and left-channel level controls for precise volume matchingvariable high- and low-pass crossovers for each channel (25-150 Hz)
dual variable-speed fans for heat dissipationDC, short circuit, and overload protection with automatic resetpower-matched to Club-series speakersfront-panel LEDs indicate Power, Active Status, and Protection Warning for easier troubleshooting

What's In the Box

P 7000s Amplifier Power cord
