AHD Indoor CCTV

Ultra Low Illumination 960P AHD Camera Indoor Dome Security CCTV Camera
1/3"Sony 2.0 Megapixel low illumination level

Sensor: SONY

MUST work with AHD DVR which support AHD-M Mode!

Best choice for project reconstruction.

You can upgrade an old analog security system to this 2.0MP HD cameras without changing cable routes.

AHD (Analog High Definition), a new video format for enhanced CVBS (COMET*) & HD video transmission.

HD AHD camera is an over-coaxial-cable analog HD video transmission standard, allowing long-distance HD transmission at a lower cost to meet the requirements for a complex and large installation.

Usually use Coaxial-Cable,SYV-75-5 cable can transfer video over 500meters.

Model: SAE50-AX3CS130

VIDEO

Image Device 1/3"Sony 2.0 Megapixel low illumination level

SENSOR SONY IMX238

TV System PAL/NTSC

Resolution 1280 (H) x 960 (V) /25fps

Min. Illumination 0Lux

Video Output 1CH AHD HD/CVBS Standard Singal Output(Switchable)

Output(Switchable)

LENS

Focal Length Standard 1080P 3.6mm (6mm/8mm)optinal

OPERATIONAL

SHUTTER/AGC Auto 1/50(1/60) ~ 1/10000 )

AGC AUTO

BACKLIGHT Compensation AUTO

White Balance AUTO

Day/Night IR-CUT Switch

Max Transmission Distance Over 500m via 75-5 coaxial cable

IR

Infrared LED 24pcs TYNTEK F5 12mil LED

IR Distance 10-20 Meters

Infrared Spectrum 850nm

ICR IR-CUT

ENVIRONMENTAL

Operation Temperature -10~ +40

Storage Temperature -20~ +50

ELECTRICAL

Input Voltage/Current DC12V,<300mA

Adapter Requirement DC12V 1A

MECHANICAL

Shell Materia ABS Plastic

Color White

Dimensions 100*100*90mm

Net Weight 250g/pcs

1*960P 1.3MP AHD Camera

Note:960P AHD Camera Must Work With AHD DVR Which Supports AHD-M,We Recommend this AHD-M DVR for you. Please click below the Picture
