XR2206 High Precision Function Signal Generator

Features:

High resolution, can generate sine/triangle/square waveforms.

Frequency range: 1Hz-1MHz.

Adjustable frequency and amplitude.

Frequency adjustment features coarse tuning and fine tuning.

Wide power supply range, use 9-12V external power or 9V battery(NOT Included).

Specifications:

Type: DIY Kit / Semi-finished Product (Optional)

Voltage Supply: 9-12V DC Input

Waveforms: Square, Sine amp; Triangle

Impedance: 600 Ohm + 10%

Frequency: 1Hz-1MHz

SINE WAVE

Amplitude: 0-3V at 9V DC Input

Distortion: Less than 1% (at 1KHz)

Flatness: +0.05dB 1Hz - 100kHz

SQUARE WAVE

Amplitude: 8V (no load) at 9V DC Input

Rise Time: Less than 50ns (at 1KHz)

Fall Time: Less than 30ns (at 1KHz)

Symmetry: Less than 5% (at 1KHz)

TRIANGLE WAVE

Amplitude: 0-3V at 9V DC Input

Linearity: Less than 1% (up to 100KHz) 10mA

Package Size: Approx. 12 * 8 * 2cm / 4.72 * 3.15 * 0.8in

Package Weight: 69g / 2.46oz
